Geovision GV-TFD4700 4MP H.265 IR Mini Fixed IP Dome Camera

AI 4MP,2.8mm,Super Low Lux,WDR Pro IR Mini Fixed,IP Dome,H.265

GV-TM0100 is an outdoor thermal IP camera capable of producing black-and-white images based on the detected temperature of the people, vehicles and environment. Unlike traditional cameras that rely on visible light, GV-TM0100 is unaffected by the lighting conditions and allows you to detect movements even in complete darkness and backlit scenes.

Ideal for border surveillance and sparsely populated areas, GV-TM0100 can detect human-sized targets at a distance of 1450 m (4757 ft) and vehicles at 1850 m (6070 ft).

GV-TM0100 can be easily configured through its Web interface and you can record and play back recordings using the GV-VMS software included in the standard package.

Key Features:

• CIF Uncooled FPA micro bolometer, 25 um pixel size
• Thermal sensitivity: ≤100 mK at f/1,300K
• Spectral range: 8 ~ 14 um
• Single stream from H.264 or MJPEG
• Up to 25 fps at 352 × 288
• 2x digital zoom
• Up to 1450 m (4757 ft) detection range for human targets and 1850 m (6070 ft) for vehicles
• Up to 480 m (1575 ft) recognition range for human targets and 920 m (3018 ft) for vehicles
• Ingress protection (IP66)
• DC 12V / PoE (IEEE 802.3af)
• Motion detection
• Privacy mask
• Text overlay
• IP address filtering
• CE, FCC, RCM, RoHS compliant
• Supports iPhone, iPad, Android & 3GPP
• 28 languages on Web interface

AI,5MP,Super Low Lux,WDR Pro,Thermal&Optical,Eyeball Dome IP Camera, Thermal 3.2mm/Optical 4mm

Key Features:

• 1/3" progressive scan low lux CMOS
• Min. illumination at 0.01 lux
• Triple streams from H.265, H.264 or MJPEG
• Up to 20 fps at 2592 x 1520
• Intelligent IR
• IR distance up to 30 m (100 ft)
• Day and Night function (with removable IR-cut filter)
• Vandal resistance (IK10 for metal casing)
• Ingress protection (IP67)
• 3-axis mechanism (pan / tilt / rotate)
• DC 12V / PoE (IEEE 802.3af)
• Built-in micro SD card slot (SD/SDHC/SDXC/UHS-I, Class 10) for local storage
• Two-way audio
• Wide Dynamic Range (WDR)
• Defog
• 3D noise reduction
• Motion detection
• Text overlay
• Privacy mask
• Tampering alarm
• ONVIF (Profile G, S, T) conformant

Geovision GV-TVD4710 4MP H.265 4.3x Zoom IR Vandal Proof IP Dome Camera, This camera will be replaced by GV-TVD4810.. Everything is the same, but with the AI function. GV-TVD4710 is EOL (end of life)

• Image Sensor 1/3” progressive scan super low lux CMOS
• Picture Elements 2592(H) x 1520 (V)
• Minimum Illumination Color : 0.005 Lux (F1.4, AGC ON)
• Minimum Illumination IR On : 0 Lux
• Shutter Speed : Automatic, Manual (1/6 ~ 1/100000 sec)
• White Balance : Automatic, Manual
• Gain Control : Automatic, Manual
• S/N Ratio : 56 dB
• WDR Pro : Yes
• Dynamic Range : Up to 120 dB

Geovision GV-TVD4711 4MP H.265 4.3x Zoom IR Vandal Proof IP Dome Camera

• Image Sensor 1/3” progressive scan super low lux CMOS
• Picture Elements 2688(H) x 1520 (V)
• Minimum Illumination Color : 0.003 Lux (F1.6, AGC ON)
• Minimum Illumination IR On : 0 Lux
• Shutter Speed : Automatic, Manual (1/6 ~ 1/100000 sec)
• White Balance : Automatic, Manual
• Gain Control : Automatic, Manual
• S/N Ratio : 56 dB
• WDR Pro : Yes
• Dynamic Range : Up to 120 dB

Geovision GV-TVD4810

Models

The Vandal Proof IP Dome is an outdoor camera designed with IK10 vandal resistance and IP67 ingress protection. GV-TVD8710 supports H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths. The camera is equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance. Adjustable in 3 axes (pan, tilt and rotate), it offers an entry-level surveillance solution with all the essential features and excellent image quality. The camera is capable of providing a color live view not only in near darkness but also under contrasting light intensities with its super low lux CMOS image sensor and WDR Pro.

• Image Sensor 1/2” progressive scan super low lux CMOS
• Picture Elements 3840 (H) x 2160 (V)
• Minimum Illumination Color : 0.003 Lux (F1.5, AGC ON)
• Minimum Illumination IR On : 0 Lux
• Shutter Speed : Auto, Manual (1/6 ~ 1/100000 sec)
• White Balance : Auto, Manual
• Gain Control : Auto, Manual
• S/N Ratio : 52 dB
• WDR Pro : Yes
• Dynamic Range : Up to 120 dB

Geovision GV-TVD8810 AI 8MP H.265 4.3x Zoom IR Vandal Proof IP Dome

• Image Sensor : 1/2.8" progressive scan low lux CMOS
• Picture Elements : 3840 (H) x 2160 (V)
• Minimum Illumination Color : 0.003 Lux (F1.6, AGC ON)
• Minimum Illumination IR On : 0 Lux
• Shutter Speed : Auto / Manual (1 ~ 1/100000 sec)
• White Balance : Auto / Manual
• Gain Control : Auto / Manual
• S/N Ratio : 56 dB
• WDR Pro : Yes
• Dynamic Range : Up to 120 dB

GV-UHF Card(ISO Card), 70x17mm , 32bits +32bits

Key Features:

• Frequency: 900 MHz
• Dimensions: 97 x 12 mm (3.8” x 0.5”)
• Operating Temperature: ‐20 ~ 85°C (‐4 ~ 185°F)

Geovision GV-UNFE2503 2MP H.264 IR Fisheye Camera

• Image Sensor 1/2.8" progressive scan super low lux CMOS
• Picture Elements 1920 (H) x 1080 (V)
• Minimum Illumination : Color 0.02 Lux
• Minimum Illumination : B/W 0.02 Lux
• Minimum Illumination IR ON : 0
• Shutter Speed : Automatic, Manual (1/5 ~ 1/8000 sec.)
• White Balance : Automatic, Manual (2800K ~ 8500K)
• Gain Control : Automatic
• S/N Ratio : 52 dB
• WDR : Yes

Key Features:

• 1/2.8" progressive scan super low lux CMOS
• Min. illumination at 0.02 lux
• Dual streams from H.264 and MJPEG
• Up to 30 fps at 1920 × 1080
• Megapixel lens
• Day and night function (electronic)
• Built-in micro SD card slot (SD/SDHC) for local storage
• Recording assigned by GV-Edge Recording Manager (Windows & Mac version)
• One-way audio
• 3D DNR (Digital Noise Reduction)
• Wide Dynamic Range (WDR)
• Defog
• Motion detection
• Tampering alarm
• Privacy mask
• Text overlay
• IP address filtering
• PoE (IEEE 802.3af)
• Supports iPhone, iPad, Android & 3GPP
• 31 languages on Web interface
• ONVIF (Profile S) conformant

Geovision GV-VD8700 8MP H.265 Face Recognition IR Vandal Proof IP Dome Camera

• Image Sensor 1/2.5" progressive scan low lux CMOS
• Picture Elements 3840 (H) x 2160 (V)
• Minimum Illumination Color : 0.05 Lux
• Minimum Illumination : B/W  0.04 Lux
• Minimum Illumination IR ON : 0 Lux
• Shutter Speed : Automatic, Manual (1/30 ~ 1/8000 sec.)
• White Balance : Automatic, Manual (2800K ~ 8500K)
• Gain Control : Automatic
• S/N Ratio : 56 dB
• WDR : Yes
• Dynamic Range : 96 dB

Key Features:

• Receive max. 128 IP channels and distribute max. 300 IP channels to other GeoVision applications
• Video gateway between IP devices and receiving clients (GV-DVR / NVR / VMS, GV-Control Center, GV-GIS, GV-Mobile Server, Multi View, GV-Edge Recording Manager and GV-Eye)
• Support 3rd party IP cameras (Sony, Axis, VIVOTEK, Panasonic, HikVision, Arecont Vision) and ONVIF / PSIA / RTSP protocols
• Bandwidth monitoring
• Two-way audio communication
• Remote configure and monitor GV-Video Gateway (Internet Explorer, Firefox, Google Chrome and Safari)
• Alert status monitoring through GV-Vital Sign Monitor

Key Features:

• Up to 288 IP channels display
• Actual size IP images display
• Adjust the size and position of each channel whether it be within or across monitors
• Max. 16 zoomed channels with Zoom Window display
• 16 Scan Window, each is capable of displaying up to 64 channels in turn, at customizable time interval
• 16 web pages display with Web Window
• 16 videos display with Media Window
• Playback 16 videos display with Remote ViewLog Window
• 288 channels of customized view region of remote monitors
• Live views display enabled from Remote E-Map

Key Features:

• Event alert text message (video lost, motion detection, I/O module lost, I/O triggered, connection lost, surveillance system abnormality, intruder, missing object, unattended object, POS loss prevention, and disk full)
• View subscribers ID, address book, storage info, camera, and input status
• Browse events for system service, connection, login/logout, motion detection, trigger, and alarm
• Send notification via alarms, SMS, and e-mail alerts
• Video/audio log keeping days notification
• Free storage space browse/report

VMS Pro 64 Channel Platform

Key Features:

• Support Fisheye Dewarping (GeoVision and 3rd party fisheye cameras)
• Support H.265 and Smart stream CODEC to reduce file size and bandwidth
• Retail Video Analytic ( People Counting / Heat Map )
• General Video Analytic (Intrusion Alarm / Crowd Detection / Scene Change Detection / Privacy Mask / Unattended and Missing Object Detection)
• Advanced Video Analytic (Human Detection / Face Recognition)
• Dual stream resolution for monitoring and recording to save CPU usage
• Quick Search Method (Timeline Search / Object Search by Area)
• Multiple monitor display for live view and playback on different monitors
• E-Map / IO Device Control / PTZ Auto Tracking
• Text alert using a PC / mobile device by motion detection / input trigger
• GeoVision Dynamic DNS server to register domain name if no fixed IP address
• Support Microsoft SQL and Access database type
• Central password management integration with Windows Active Directory
• Support GeoVision, 3rd party IP camera and ONVIF, PSIA, RTSP protocol
• Support GeoVision central monitoring station software (GV-Center V2 / GV-Vital Sign Monitor / GV-Dispatch Server / GV-Control Center)
• Mobile Remote Viewing (GV-Eye for Android Smartphone and iPhone / iPod / iPad)

Virtual Dongle GV-VMS Pro 64 Channel Platform
