Ethernet

Gigabit Ethernet 10/100/1000Mbps (RJ45)

1

Standards

IEEE 802.3 10-BASE-T (Ethernet)

Supported

IEEE 802.3u 100-BASE-TX (Fast Ethernet)

Supported

IEEE 802.3ab 1000-BASE-T (Gigabit Ethernet)

Supported

IEEE 802.3at Power over Ethernet Plus

Supported

Transmission Media

10Base T

Cat. 3, 4, 5 UTP/STP

100Base TX

Cat. 5, 5e UTP/STP

1000Base T

Cat. 5e, 6, 7 UTP/STP
* It is highly recommended to use standard Cat. 5e/6/7 cables which are compliant with the 3P/ETL standard.

PoE Function

Number of PoE Port

1

Max. PoE Output Power/Per Port

54VDC/95W

802.3at Standard Compatible

Yes

Over Current Protection

Supported

Circuit Shorting Protection

Supported

Total PoE Power Budget

95W

Power Pin Assignment

1/2(-), 3/6(+), 4/5(+), 7/8(-)

PoE PD Auto Detection

Supported

General

LED Indicators

Power, PoE

Power Input

100~240V AC / 50~60Hz

Power Consumption

100W

Surge Protection Data/ PoE port

12KV

Surge Protection AC Power

4KV

Dimensions

182 (L) x 78.6 (W) x 41.9 (H) mm

Weight

0.58 kg

Operating Temperature

-20°C ~ 30°C (-4°F ~ 86°F) @ 95W
-20°C ~ 40°C (-4°F ~ 104°F) @ 80W
-20°C ~ 50°C (-4°F ~ 122°F) @ 70W

Storage Temperature

-20°C ~ 70°C (-4°F ~ 158°F)

Humidity

Operating: 10~90% (Non-condensing)
Storage: 10~90% (Non-condensing)

Safety Certifications

CE, C-Tick, FCC, VCCI, LVD

Accessories

Included Accessories

Power cord, QIG
