IP Camera Compatibility

Video Resolution

Megapixel/D1/VGA

Video Compression

MJPEG/MPEG-4/H.264/H.265

Compatible Camera List

VIVOTEK Network Cameras

Ethernet

Gigabit Ethernet (RJ45)

8

Gigabit Ethernet (SFP)

2

Standards

IEEE 802.3 10-BASE-T (Ethernet)

Supported

IEEE 802.3u 100-BASE-TX (Fast Ethernet)

Supported

IEEE 802.3ab 1000-BASE-T (Gigabit Ethernet)

Supported

IEEE 802.3x Flow Control (Full-Duplex Flow Control)

Supported

IEEE 802.3af Power over Ethernet

Supported

IEEE 802.3at Power over Ethernet Plus

Supported

Ethernet Performance

MAC Address

8 K

Buffer Memory

128 KB

Transmission Method

Store and Forward

Backplane

20 Gbps

Jumbo Frame

9 K

Auto-MDI/MDI-X, Auto-Negotiation

Supported

Filtering/Forwarding Rates

10Mbps

14,880 pps

100Mbps

148,000 pps

1000Mbps

1,488,000 pps

Transmission Media

10Base T

Cat. 3, 4, 5 UTP/STP

100Base TX

Cat. 5, 5e UTP/STP

1000Base T

Cat. 5e, 6, 7 UTP/STP
* It is highly recommended to use standard Cat. 5e/6/7 cables which are compliant with the 3P/ETL standard.

PoE Function

Number of PoE Out Ports

8

PoE Power Output

Per Port 56VDC, Max. 30W

Total PoE Power Budget

115W

802.3at/af Standard Compatible

Yes

Over Current Protection

Supported

Circuit Shorting Protection

Supported

Power Pin Assignment

1/2(+), 3/6(-)

PoE PD Auto Detection

Yes

General

LED Indicators

Power, LANx10, PoEx8

Power Input

100~240VAC / 50~60Hz

Power Consumption

120W

Operating Temperature

0°C ~ 50°C (32°F ~ 122°F)

Storage Temperature

-20°C ~ 70°C (-4°F ~ 158°F)

Operating Humidity

10~90% (Noncondensing)

Dimensions

280 (L) x 214 (W) x 44 (H) mm

Weight

1.19 kg

Safety Certifications

CE, C-Tick, FCC, LVD, VCCI

Accessories

Included Accessories

Power cord, QIG, 19″ rack mount kit

Optional Accessories

SFP Transceiver:
SFP-1000-MM85-X5: MMF, 0.5 km, 0°C ~ 70°C
SFP-1000-MM13-02: MMF, 2 km, 0°C ~ 70°C
SFP-1000-SM13-10: SMF, 10 km, 0°C ~ 70°C
SFP-1000-SM13-40: SMF, 40 km, 0°C ~ 70°C
